| Rated Output | 额定输出 | 2.0mV/V ±2.5% |
| Zero Balance | 零点平衡 | ±3%(< 100kg) / l%(200kg~5t) of rated output |
| Creep after 30 minutes | 蠕变 | ±0.03% of rated output |
| Nonlinearity | 非线性 | ±0.03% of rated output |
| Hysteresis | 滞后 | ±0.03% of rated output |
| Repeatability | 重复性 | ±0.03% of rated output |
| Temp, effect on output | 灵敏度温漂 | <0.002% of applied output/℃ |
| Temp, effect on zero | 零点温漂 | <0.002% of rated output/℃ |
| Safe Temp. Range | 可用温度范围 | -10℃ to + 70℃ |
| Temp. Compensated | 温度补偿范围 | -10℃ to + 40℃ |
| Safe Overload | 安全载荷 | 150% |
| Input Impedance | 输入阻抗 | 387 ohm ± 50 ohm |
| Output Impedance | 输出阻抗 | 350 ohm ± 5 ohm |
| Insulation Resistance | 绝缘阻抗 | >5000 M ohm (50V DC) |
| Rated Excitation | 推荐激励电压 | 10V DC/AC |
| Maximum Excitation | 最大激励电压 | 15V DC/AC |
| Cable Length | 导线长度 | 2.75m |
| Cable Color Code | 导线颜色 | Red( + E) Black(-E) Green( + S) White(-S) |
